MEAN WELL DDR-480C-48 Isolated 33.6-67.2Vin 48V 10A 480W DIN
Manufacturer: MEAN WELL Model: DDR-480C-48 - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Width: 85.5 mm
Height: 125.2 mm
Length: 129.2 mm
Industry: Industrial
Compliance: EN50155, EN45545-2
Unit Weight: 1.375 kg
Output Power: 480 W
Input Voltage: 33.6 V to 67.2 V
Mounting Style: DIN Rail
Isolation Voltage: 4 kV
Number of Outputs: 1 Output
Input Voltage - Max: 67.2 V
Input Voltage - Min: 33.6 V
Output Current-Channel 1: 10 A
Output Voltage-Channel 1: 48 V
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 40 C
