Display: 4.3-inch high-definition LCD touch screen
Reading digits: 5 and a half positions
Measurement range: 1μΩ~20MΩ
Resistance range: 20mΩ / 200mΩ / 2Ω / 20Ω / 200Ω / 2kΩ / 20kΩ / 100kΩ / 1MΩ / 10MΩ / 100MΩ
Basic measurement accuracy: 0.1% (refer to the user manual for detailed information)
Resistance measurement time: fast: 7ms, medium speed: 42ms, slow speed: 150ms
Temperature measurement time: 50 ± 10ms
Test end configuration: four terminals
Low voltage measurement: open circuit voltage ≤ 60mV, effective range: 2Ω, 20Ω, 200Ω, 2kΩ
Thermoelectric elimination: √
Statistical functions: Qualified and unqualified
Measurement settings parameters: Save 10 sets
Temperature measurement: sensor: PT1000 -200.0℃~300℃; display: -99.9℃~999.9℃
Other functions: temperature compensation
Comparator – Signal output: HI/IN/LO
Comparator – Sound: Call mode: OFF, IN, HI/LO
Comparator – Limit setting: mode 3, absolute value upper/lower
Interface configuration: standard: RS232/RS485, USB interface HANDLERS
Standard accessory: power cord, four terminal low resistance test wire, PT1000 thermal resistor
