Manuafacturer: Metrix
Model : MTX 3293
Item: MTX3293-BT
Warranty : 12 month
Specifications
- DC, AC and AC+DC voltages : -40 to +1,200°C
- DC accuracy: 0.02%
- AC and AC+DC bandwidth: 200 kHz
- DC, AC and AC+DC current : 1,000 μA to 10 A / 20 A (30 s max)
- DC accuracy: 0.01%
- Frequency : 10 Hz to 5 MHz
- Resistance: 100 Ω to 100 MΩ
- Audible continuity : 1000Ω SIGNAL <20 Ω< 3.5V
- Diode test : Diode 0 -2.6 V <1 mA + Zener Diode or LED 0-20 V<11 mA
- Capacitance : 1 nF to 10 mF
- Temperature Pt100/1000: -200°C to 800°C
- Temperature K/J TC : -40 to +1,200°C
Other functions
- Surveillance: SURV time/date-stamped MAX/MIN /AVG or PEAK ±, on all the main positions
- REL: Relative value REF-delta unit or on 3 displays + main measurement
- PWM filter : 4th-order 300 Hz low-pass filter for measuring on variable speed drives of asynchronous motors
- V-output clamp function for direct reading: Parameterizable Ax ratio
- Secondary functions or measurements: 3 measurements + main measurement
- SPEC: Display of measurement tolerance: Smin, Smax
- GRAPH: Trends of main measurements <60s + Zoom + Cursor
- Central zero: Automatic trend bargraph
- Measurement storage: 6,500
General specifications
- Type of display: Colour graphical display (70x52) with backlighting on 4 100,000-count displays
- PC interfaces: USB optical connector or Bluetooth (option)– SX-DMM software
- Alimentation: Charger or 4 x AA batteries or Ni-MH batteries
- Safety: Safety as per IEC 61010-1 1,000V-CAT III /600V CAT IV – Safety as per IEC 61010-2-033
- Environment: Storage: -20 °C to +70 °C – Operation: 0 °C to +40 °C
- Mechanical specifications: Dimensions (L x W x H): 196x90x47.1 mm – Weight: 570 g
State at delivery: delivered with 1 bag, 4 NI-MH 2400mAH 1.5 V rechargeable batteries, 1 charger, 1 red straight/straight lead 1.5 m long,
1 black straight/straight lead 1.5 m long, 1 red CAT IV 1 kV test probe,
1 black CAT IV 1 kV test probe, 1 optical USB cable + SX-DMM software,
1 user’s manual on CD and 1 user’s programming manual SCPI,1 start-up guide on paper
Accessories:
- MTX329X graphical colour calibration software (HX0059B)
- Kit of 4 Ni-MH rechargeable batteries (HX0051B)
- External charger MTX 328X, MTX 329X (4 batteries included) (HX0053B)
- MTX digital DMM transport kit (HX0052B)
- Graphical colour DMM transport kit (HX0052C)
- MTX 3290 / 3291 calibration software (P01196770)
