Test Frequency:0.1Hz-200kHz
Points Of Test Frequency: Continuity
Basic Accuracy: ± 0.08%
AC Drive Level: 10mV to 2Vrms (1m Vrms solution)
DC Drive Level: 0.01V-2V
Output Impedance: 100Ω
Frequency trimming resolution: 5 Digits
Frequency output accuracy: ±0.01%
AC / DC test speed Max.: 8mS
Measured Value Detection Mode:Define upper and lower thresholds according to main and sub parameters
ESR:Series/Parallel
Test Mode:Meter mode/Multi-step mode
Test Range:Automatic/Lock
Indicator:Pass/Fail and Built-in speaker
Safety:EN61010-1
Immunity:EN61326-1
Emissions:EN55022 Class A
Calibration:Open Circuit / Short Circuit: Avoid the misreading caused by the stray capacitance from kelvin clips and fixtures
Auto-save when power-off function:When the power is turned off or encounter a power outage, all the data will be saved automatically and recovered when tester system is switched on again
Power Supply:Voltage 90-132Vac or 198-264Vac (selectable)
Frequency: 47 ~ 63Hz
Display800*480 Color Screen, 7" TFT
Interface:RS-232, GPIB, Handler, USB
Flash Memory:Built-in flash for storage of 128 groups of Multi-steps setting
Operation:Auto、Manual、RS-232、GPIB、Handler
Temperature : 10°C to 40°C
Humidity : 20 ~ 90%
Dimension (W*H*D):344x145x343 mm
Weight:3 Kg
Standard Accessories
Power Cord,User Manual,F423501
Optional Accessories
F423503,F423903,F423905
