Capacity/Resolution: 1/0.0001 N.m; 100/0.01 N.cm; 10/0.001 kgf.cm; - lbf.ft; 8.85/0.001 lbf.in; 1~10 mm Drill Chuck
Range: 5%~100% Capacity
Accuracy: ± 0.3% @Readings
Selectable Units: N.m、N.cm、kgf.cm、lbf.ft、lbf.in
Display: 160*128 dot matrix LCD(2.8 inch) with LED Backlight
Overload Capacity: 120% F.S.
Measurement Mode: Track, Peak, First Peak,Auto Peak, Auto First Peak
Display Mode: Digital / Curve
Sampling Rate: Up to 2KHz
Memory: 1000 data
Set Point: Programmable high and low limits
Battery Indicator: Display flashes battery icon when battery is low
Power: 3.6VDC 800mAH Ni-Mh rechargeable batteries
Battery Life: Approx. 14 hours for continuous use
Charger: Universal USB/BM charger, Input:110~240VAC
Temperature Effects: <0.03% FS per °C
Communication: USB or RS-232
Software: Free software for USB communication
Outputs: RS-232, "Within" set point output， "Under or over" set point output
Operating environment: Temperature: -10 to 40°C; Relative Humidity: 20 to 80%
Storage environment: Temperature: -20 to +50°C; Relative Humidity: 5 to 90%
Accessories: AC adapter/charger, USB cable
Options: Mini-printer, Measuring Adapters, RS-232 Cable, EST-TT2 Torque Test Stand
