Turret: manual
Test range: 8~650HBW
Test force: 62.5kgf, 100kgf, 125kgf, 187.5kgf, 250kgf, 500kgf, 750kgf, 1000 kgf, 1500kgf, 3000kgf
N: 612.9N, 980.7N, 1226N, 1839N, 2452N, 4903N, 7355N, 8907N, 14710N, 29420N
Hardness Scale: HBW2.5/31.25, HBW2.5/62.5, HBW2.5/187.5, HBW5/62.5, HBW5/125, HBW5/250, HBW5/750, HBW10/100, HBW10/250, HBW10/500, HBW10/1000, HBW10/1500,HBW10/3000
Conversion Scale: HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK, HS, HV, HK, HBW, HR15, HR30, HR45N, HR15T, HR30T, HR45T
Indentor size: Φ2.5mm, Φ5mm, Φ10mm
Optical System: Eyepiece: 20x, Objective: 1x, Total Magnification: 20x
Test height: 280mm
Test throat: 150mm
Dwelling time: 0~99s
Power supply: AC220V, 50Hz
Machine dimension: 230*600*920mm
Net weight: 130kg
Standard delivery:
Main frame: 1 set
Measuring Eyepiece: 1 pc
Ф150mm Test Anvil: 1 pc
Ф78mm Test Anvil: 1 pc
78mm V-shape Test Anvil: 1 pc
Ф10mm Hard Alloy Brinell Indenter: 1 pc
Ф5mm Hard Alloy Brinell Indenter: 1 pc
Ф2.5mm Hard Alloy Brinell Indenter: 1 pc
Brinell Hardness Block HB10/3000, HB10/1000:2 pcs
Hard Alloy Steel Ball 2.5/5/10mm: each 1 pc
