Cutting Capacity: 80mm（Pipe）
Feed Depth Tracking: LCD Digital Display
Platform Y-axis Movement: 275mm
Cutting Table Dimensions: 310X280mm
Cutting Disc Specifications: 350X2.5X32mm
Clamping Table Specifications: The Fixture Is Divided Into Left And Right, With A Central Cutting Edge
Cutting Method: Manual/ Automatic
Feeding Method: Adjustable (Manual, Automatic)
Cutting Speed:
0.1-2.5mm/s, Automatic Cutting Mode Can Be
Selected: Intermittent Cutting (Metal Workpiece)
And Continuous Cutting (Non-metal Workpiece)
Feed Distance: Arbitrary Setting (0-200mm)
Reset Method: Automatic Reset
Cooling System: Automatic (Water Cooling 3 Channels)
Water Tank Capacity: 50L
Spindle Speed: 2150rpm
Motor Power: 3kw
Machine Type: Desktop
Machine Dimension:900×790×600mm
Power Supply: 380V
Gross Weight: 150KG
Standard Delivery
Machine Mainframe: 1 set
Water Tank (including water pump): 1 pc
Cut-off Wheel 350*2.5*32mm: 2 pcs
Pipe Clamp: 4 pcs
Wrench 24-27mm: : 1 pc
Wrench 36mm: 1 pc
Inlet Pipe: 1 pc
Outlet Pipe: 1 pc
Optional Delivery
Aluminum Oxide Cut-off Wheels: A060/A050/A030
Cutting Fluid: CF-1L/CF-4L
Vertical Fixture: MS-VF
