X*Y Motion Range(mm): 300*200
Z-axis Motion Range (mm): 150
External Dimensions(mm): 750×520×1180
Net Weight(kg): 180
Workbench Load-bearing Capacity(kg): 30
Image Sensor: Optional
Metallographic Lens: Optional
Accuracy(um): X/Y: 2.0+L/200µm
Minimum Display unit(mm): 0.0001
Light Source
Surface light:LED coaxial light source
Bottom light source:LED parallel light source
Software: Mikromea-M 2.5D Manual Measuring Software
Working Environment
Temperature: 22℃±2℃
Humidity: 30~80%
Vibration: <0.002mm/s,<15Hz
Power: 220V/50Hz
STANDARD DELIVERY
Objectives: 1pc
5X、10X、20X、50X；100X(Optional): 1pc
5-hole Adapter(6-hole Optional): 1pc
Illuminator: 1pc
Eyepiece Tube: 1pc
Measuring Software: 1pc
OPTIONAL DELIVERY
Objective Lens Plan FL N 100X/ NA0.8/ WD3mm: MS-OB03-100X
0.1μm Digital Linear Scale: MS-LS-01
6 Position Nosepiece: MS-ONP
Illuminator (Olympus): MS-OIM
Eyepiece Tube(Olympus): MS-OET
