Test force
Rockwell: 60kgf, 100kgf, 150kgf
Superficial Rockwell: 15 kgf, 30 kgf, 45 kgf
Brinell: 5kgf, 6.25kgf, 10kgf, 15.625kgf, 30kgf, 31.25kgf, 62.5kgf, 100kgf, 125kgf, 187.5kgf, 250.0kgf
Vickers:5kgf, 10kgf, 20kgf, 30kgf, 40kgf(392N), 50kgf, 60kgf, 80kgf, 100kgf, 120kgf
Force Error: ＜0.5%
Brinell Scale: HBW1/5, HBW2.5/6.25, HBW1/10, HBW2.5/15.625, HBW1/30, HBW2.5/31.25, HBW2.5/62.5, HBW10/100, HBW5/125, HBW2.5/187.5
HBW5/250, HBW10/250
Rockwell Scale: HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK, HRL, HRM, HRP, HRR, HRS, HRV
Superficial Rockwell Scale (uBRV-250): 15N, 15T, 15W, 15X, 15Y, 30N, 30T, 30W, 30X, 30Y, 45N, 45T, 45W, 45X, 45Y
Vickers Scale: HV5, HV10, HV20, HV30, HV40, HV50, HV60, HV80, HV100, HV120
Hardness Resolution: 0.1HBW, 0.1HR, 0.1HV
Indication Accuracy: Brinell: ±2.5HB; Rockwell:±0.1HR; Vickers:±2 HV
Repeatability: Brinell:≤3.0HB; Rockwell: 0.5HR; Vickers: ≤2.5HV
Magnification
Eyepiece: 15X
Objective: 2.5X(for Brinell), 5X (for Vickers) (10X, 20X for optional)
Total Magnification: 37.5X, 75X Brinell：37.5X, Vickers：75X
Minimum Measuring Unit: 0.1µm
Dwelling Time: 0-60s
Hardness Range: Brinell：8～650HBW Rockwell：20～100HR Vickers：8～2900HV
Data Output: LCD display，U disk
Test Height: Rockwell：220mm、 Brinell /ickers：150mm
Test Throat: 200mm
Executive Standards
ISO 6508，ASTM E-18，JIS Z2245，GB/T 230.2
ISO 6506，ASTM E10-12，JIS Z2243，GB/T 231.2
ISO 6507，ASTM E92，JIS Z2244，GB/T 4340.2
Dimensions: Machine Size: 560*350*800mm, Packing Size: 730x450x910mm
Weight: N/W: 70kg; G/W: 99kg
Power: AC220V+5%，50-60Hz
