Units: Torr
Compatible with: Dual Convectron Gauge
Electrical Plug: North America and Japan 115 VAC
Measurement Range: Torr: 5x10^-10 to 5x10^-2 (to 1000 Torr with Convectron option)
Display: 2 digits plus exponent, green LED
Display Update Rate: Every 0.5 sec
Power Requirements: 100 to 240 Vac, 50 to 60 Hz, 50 W max
Communication Protocol: RS-485/422
Analog Output: Micro-Ion: 1 Volt/decade, logarithmic, 0 to 10 V
Set Point Contact Rating: 5 A at 30 Vdc, 5 A at 120 Vac, 4 A at 240 Vac, resistive load
Set Point Configuration: 6 set point relays, 2 per channel
Operating Temperature: 0° to 40°C
Storage Temperature: -40° to 70°C
Case Materials: Aluminum extrusion
Connector: 9-pin subminiature-D male
Weight: 1.8 kg (4 lbs)
