ADC Native Resolution: 14-bit
AI latency and repeatability: Response Time: 300µsec ±10%
Number of Inputs: 4, Single Ended (1 for each pressure signal input)
Power Consumption: 24 V Core: 3.5 W, 24 V IO: Maximum 120 W
(When all 4 pressure devices consume 0.8Amp Maximum each from ±15 V power supply)
Connector: 15 pin D-sub
Maximum Current Delivery per connector: 0.8 Amps
Input Voltage: 24 VDC
Maximum error over full range: ±0.15% of Full Scale (20°C to 30°C)
Minimum Input CMRR: 50 dB, 0-1 kHz
Minimum Input Impedance: 1 Meg-ohm
Protection: ESD to IEC 61000-4-2 ±4 kV contact,
Sampling Rate: 6.25 kHz (160µsec, for all 4 channels) short to 24 V, +15 V, or -15 V
Operating Temperature: 0 - 40°C, with 2°C upper limit reduction per 1000 ft above sea level.
Note: At 40°C ambient, power consumption of the ±15V power supply should be limited to 100W (3.3A @ both ±15V) The pressure module should be located as the last module (right-most module in a stack)
Storage Temperature: -40 - 75°C
Humidity: 5 - 95% non-condensing
Dimensions: 52.5 x 125 x 92.3 mm
Mounting: DIN rail
