Gain: 2.2 dBi, 3.5 dBi
Style: I-Bar Flex
Width: 11 mm
Height: 0.1 mm
Length: 35 mm
Impedance: 50 Ohms
Cable Type: 50 mm Coax
Technology: WiFi
Unit Weight: 541 mg
Cable Length: 50 mm
For Use With: Home Automation, Connected Vehicle, Custom Solutions
Polarization: Linear
Power Rating: 2 W
REACH - SVHC: Details
Mounting Style: Adhesive Mount
Number of Bands: 2 Band
Center Frequency: 2.45 GHz, 5.5 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 5.85 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: IPEX MHF
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 30 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE)
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
