Input Functions:
- DC Voltage (Reference/ Ranges/ Resolution/ Accuracy/Remarks):
+ 50 mV/ -5 to 55 mV/ 1 mV/ 0.02 + 0.02/Input Resistance 100 MΩ
+ 500 mV/ -50 to 550 mV/ 10 mV/ 0.02 + 0.01/Input Resistance 100 MΩ
- Resistance (Ohm) (Reference/ Ranges/ Resolution/ Accuracy/Remarks):
+ 500 Ω/ 0 to 550 Ω/ 0.01 Ω/ 0.05 + 0.02/ _
+ 5 KΩ/ 0 KΩ to 5.5 KΩ/0.1 Ω/ 0.05 + 0.02/ _
- Thermocouple (Reference/ Ranges/ Resolution/ Accuracy/Remarks):
+ R: 0 to 1767°C/ 1°C/ 0 to 500°C: 1.8°C/ _
+ S: 0 to 1767°C/ 1°C/ 500 to 1767°C: 1.5°C/ _
+ K: -100 to 1372°C/ 0.1°C/ -100 to 0°C: 1.2°C; 0 to 1372°C: 0.8°C/ _
+ E: -50 to 850°C/ 0.1°C/ -50 to 0°C: 0.9°C; 0 to 850°C: 1.5°C/ _
+ J: -60 to 1120°C/ 0.1°C/ -60 to 0°C: 1°C; 0 to 1120°C: 0.7°C/ _
+ T: -100 to 400°C/ 0.1°C/ -100 to 0°C: 1°C; 0 to 400°C: 0.7°C/ _
+ N: -200 to 1300°C/ 0.1°C/ -200 to 0°C: 1.5°C; 0 to 1300°C: 0.9°C/ _
+ B: 600 to 1820°C/ 1°C/ 600 to 800°C: 2.2°C; 800 to 1000°C: 1.8°C; 1000 to 1820°C: 1.4°C/ _
+ L: -60 to 900°C/ 0.1°C/ -60 to 0°C: 0.7°C; 0 to 900°C: 0.5°C/ _
+ U: -100 to 600°C/ 0.1°C/ -100 to 0°C: 0.7°C; 0 to 600°C: 0.5°C/ _
-RTD (Reference/ Ranges/ Resolution/ Accuracy):
+ Pt100 385/ -200 to 800°C/ 0.1°C/ -200 to 0°C: 0.5°C
/ 0 to 400°C: 0.7°C
/400 to 800°C: 0.8°C
+ Pt1000 385/ -200 to 630°C/ 0.1°C/ -200 to 100°C: 0.8°C
/ 100 to 300°C: 0.9°C
/300 to 630°C: 1.0°C
+ Pt200 385/ -200 to 630°C/ 0.1°C/ -200 to 100°C: 0.8°C
/ 100 to 300°C: 0.9°C
/300 to 630°C: 1.0°C
+ Pt500 385/ -200 to 630°C/ 0.1°C/ _
+ Cu10/ -100 to 260°C/ 0.1°C/ 1.8°C
+ Cu50/ -50 to 150°C/ 0.1°C/ 0.7°C
Continuity (Reference/ Ranges/ Resolution/ Accuracy/Remarks):
500 Ω/ <50 Ω round/ 0.01 Ω/ _/ Excitation Current approx.. 1 mA
Output Functions:
- DC Voltage (Reference/ Ranges/ Resolution/ Accuracy/Remarks):
+ 100 mV/ -10 to 110 mV/ 1 mV/ 0.02 + 0.01/ Maximum Output: 0.5 mA; Maximum Output: 2 mA
+ 1000 mV/ -100 to 1100 mV/ 10 mV/ 0.02 + 0.01/ Maximum Output: 0.5 mA; Maximum Output: 2 mA
- Resistance (Ohm) (Reference/ Ranges/ Resolution/ Accuracy/Remarks):
+ 400 Ω/ 0 to 400 Ω/ 0.01 Ω/ 0.02 + 0.02/ _
+ 4 KΩ/ 0 KΩ to 4 KΩ/0.1 Ω/ 0.05 + 0.025/ _
- Thermocouple (Reference/ Ranges/ Resolution/ Accuracy/Remarks):
+ R: 0 to 1767°C/ 1°C/ 0 to 100°C: 1.5°C/ ITS-90
/ 100 to 1767°C: 1.2°C/
+ S: 0 to 1767°C/ 1°C/ 0 to 100°C: 1.5°C/ ITS-90
/100 to 1767°C: 1.2°C/
+ K: -200 to 1372°C/ 0.1°C/ -200 to -100°C: 0.6°C/ ITS-90
/-100 to 400°C : 0.5°C/
/400 to 1200°C: 0.7°C/
/1200 to 1372°C: 0.9°C/
+ E: -200 to 1000°C/ 0.1°C/ -200 to 100°C: 0.6°C/ ITS-90
/ -100 to 600°C: 0.5°C/
/ 600 to 1000°C: 0.4°C/
+ J: -200 to 1200°C/ 0.1°C/ -200 to -100°C: 0.6°C/ ITS-90
/ -100 to 800°C: 0.5°C/
/ 800 to 1200°C: 0.7°C/
+ T: -250 to 400°C/ 0.1°C/ -250 to 400°C: 0.6°C/ ITS-90
+ N: -200 to 1300°C/ 0.1°C/ -200 to -100°C: 1.0°C/ ITS-90
/ -100 to 900°C: 0.7°C/
/ 900 to 1300°C: 0.8°C/
+ B: 600 to 1820°C/ 1°C/ 600 to 800°C: 1.5°C; 800 to 1820°C: 1.1°C/ ITS-90
+ L: -200 to 900°C/ 0.1°C/ -200 to 0°C: 0.7°C; 0 to 900°C: 0.5°C/ ITS-90
+ U: -200 to 600°C/ 0.1°C/ -200 to 0°C: 0.7°C; 0 to 600°C: 0.5°C/ ITS-90
- RTD (Reference/ Ranges/ Resolution/ Accuracy):
+ Pt100 385/ -200 to 800°C/ 0.1°C/ -200 to 0°C: 0.3°C
/ 0 to 400°C: 0.5°C
/400 to 800°C: 0.8°C
+ Pt1000 385/ -200 to 630°C/ 0.1°C/ -200 to 100°C: 0.8°C
/ 100 to 300°C: 0.9°C
/300 to 630°C: 1.0°C
+ Pt200 385/ -200 to 630°C/ 0.1°C/ -200 to 100°C: 0.4°C
/ 100 to 300°C: 0.5°C
/300 to 630°C: 0.7°C
+ Pt500 385/ -200 to 630°C/ 0.1°C/ -200 to 100°C: 0.2°C
/ 100 to 300°C: 0.5°C
/300 to 630°C: 0.7°C
+ Cu10/ -100 to 260°C/ 0.1°C/ 1.8°C
+ Cu50/ -50 to 150°C/ 0.1°C/ 0.6°C
Standard delivery:
Process Meter – Model : Nagman 05+
1.5V ‘AAA’ Alkaline Batteries (4 Nos.)
Operation Manual
Test Leads
Traceable Calibration Certificate
Optionals:
Calibration Certificate from NABL Accredited –as per ISO/IEC 17025:2005 Laboratory
