Initial test force: 98.07N（10kgf）
Test force
Rockwell:588N（60kgf）,980N（100kgf）,1471N（150kgf)
Brinell:153.2N(15.625kgf),306.5N（31.25kgf）,612.9N（62.5kgf） 1226N(125kgf)，1839N（187.5kgf)
Vickers:49.03N（5kgf）、98.07N（10kgf）、196.1N（20kgf）; 294.2N(30kgf)、490.3N(50kgf)、980.7N（100kgf）
Ruler range
Rockwell：HRA、HRB、HRC、HRD、HRF、HRG
Brinell：HBW2.5/15.625、 HBW2.5/31.25、 HBW2.5/62.5; HBW2.5/187.5、HBW5/125、HBW5/62.5
Vickers：HV5、HV10、HV20、HV30、HV50、HV100
Measuring range
Rockwell：20-95HRA、10-100HRBW、20-70HRC
Brinell：5-650HBW
Vickers：5-3000HV
Magnification: 25X、50X、100X
The distance from the center of the indenter to the fuselage: 160mm
Specimen allowable maximum height: Rockwell：210mm（limit）; Brinell、Vickers：180mm
Dimensions: 550*290*780mm
Power supply: AC220V/50Hz
