Printing Technology: Direct thermal, thermal transfer
Resolution: 300 dpi (12 dots/mm)
Maximum Print Width: 105 mm
Print Speed: 100 mm/s
CPU: 32-bit RISC MPU
Programming Languages: BPLE, BPLZ, BPLT
Memory: FLASH 8 MB; SDRAM 32 MB
Interfaces: USB, serial port, Ethernet
Media Types: Continuous paper, label paper, tag paper, etc.
Label Roll Size: Outer diameter: up to 127 mm; Width: up to 110 mm; Inner diameter: 25 mm / 38 mm
Media Thickness: 0.06 – 0.20 mm
Ribbon Core Diameter: 12.5 mm / 25.4 mm
Ribbon Outer Diameter: up to 65 mm
Standard Ribbon Length: up to 300 m
Paper Cutting: Tear-off
Barcode Support:
1D: Code39, Code93, Codabar, Code128 (Subsets A, B, C), EAN-13, EAN-8, UPC-A, UPC-E, UPC/EAN Extensions, Planet Code, Standard 2 of 5, Industrial 2 of 5, Interleaved 2 of 5, LOGMARS, GS1 DataBar (RSS)
2D: PDF417, MicroPDF417, QR Code, DataMatrix, MaxiCode, GS1 Composite
Dimensions (L × W × H): 278 × 218 × 185 mm
Weight: 2.3 kg
Buttons and LEDs: 1 button and 2 LEDs
Power Adapter: Input: AC 100–240 V, 50/60 Hz; Output: DC 24 V, 2.5 A
Operating Temperature / Humidity: +5°C to +45°C (45°F–113°F), 20%–90% RH
Storage Temperature / Humidity: –40°C to +60°C (–40°F–140°F), 20%–93% RH
Software Compatibility: Windows, Linux, Android, Mac
