Output power: 10.5 kVA
Polyphase system:
+ A polyphase system can be configured by connecting multiple units of the same single-phase model.
+ Single-phase three-wire system: 3 kVA, 6 kVA, 9 kVA, 12 kVA, 15 kVA, 18 kVA, 21kVA, 24 kVA, 48 kVA, 72 kVA
+ Three-phase system: 4.5 kVA, 9 kVA, 13.5 kVA, 18 kVA, 22.5 kVA, 27 kVA, 31.5 kVA, 36 kVA, 72 kVA, 108 kVA
AC/DC mode: AC, ACDC, DC
AC output:
+ Voltage setting range:
Phase voltage: 0.0 V to 160.0 V/0.0 V to 320.0 V, 0.0 Vp-p to 454.0 Vp-p / 0.0 Vp-p to 908.0 Vp-p (arbitrary waveform)
Line to line voltage: -
Resolution: 0.1V
+ Max. current: 105 A/52.5 A
+ Max. peak current: 4 times value of maximum current
+ Load power factor range: 0 to 1 (lead or lag, at 45 Hz to 65 Hz)
+ Frequency setting range, output waveform: 40.00 Hz to 550.00 Hz (AC mode), 1.00 Hz to 550.00 Hz (ACDC mode), resolution: 0.01 Hz, waveform: sine, arbitrary (16 types), clipped Sine (3 types)
+ Output voltage stability : Line regulation: within ±0.15%, load regulation: within ±0.15 V/±0.3 V (45 Hz to 65 Hz), within ±0.5 V/±1.0 V (40 Hz to 550 Hz) (phase voltage)
+ Output voltage distortion factor: 0.5% or less (40 Hz to 550 Hz, 50% or more of rated output voltage, maximum output current or below, AC mode or ACDC mode) (phase voltage)
DC output
+ Output power: 10.5 kW
+ Voltage setting range: −227 V to +227 V/−454 V to +454 V, resolution: 0.1 V
+ Max. current: 105 A/52.5 A
Measurement function:
+ Voltage: RMS value (rms), DC average (avg) (only single-phase models), peak value (pk)
+ Current: RMS value (rms), DC average (avg) (only single-phase models), peak value (pk), peak hold value
+ Power: Effective (W), apparent (VA), reactive (var) (option)
+ Others: Load power factor (option), load crest factor (option), synchronization frequency, harmonic current(option), CO2 emissions (excluding 24 kVA and 36 kVA model)...
Power input (specified on order): AC100 V to 230 V ±10%, 3P3W AC200 V to 220 V ±15% or 3P4W AC380 V ±15%; 50 Hz/60 Hz ±2 Hz
Efficiency: 77% or more (typ., at AC200 V input)
Power consumption (maximum): 15.8 kVA
Weight (approx.): 140 kg
Dimensions (W×H×D): 430 × 1287 × 562 mm
