Maximum Exercise Pressure 10,000 Kg
Set of 2 heating plates 300 x 300 mm in special aluminum alloy, each equipped with n°4 / 0.8 kVA cartridge heater
Control panel with digital electronic display, thermo regulators (temperature range 0 ÷ 300°C), for the independent thermoregulation of each plate
Optional PLC with touch-screen display allowing to set molding cycles defining the temperatures
Optional PLC with touch-screen display defining the thermal cycle (temperature gradients)
Optional PLC with touch-screen display defining the closing force (option)
Optional PLC with touch-screen display allowing memorization of the cycles
A cooling coil is inserted in each heating plate to connect to an air or water circuit supply
Cooling is necessary up to the solidification temperature before opening the mold
The heating plates are also equipped with a thermostat against overheating
The lower plate is lifted with an hydraulic piston, while the upper plate is fixed
Technical Specifications
Opening of the plates 0 ÷ 150 mm
Range of pressure 10 ÷ 100 kN (10T)
Advisable max working pressure 680 ÷ 700 bar
Working temperature ambient ÷ 300°C
Dimensions 93 x 69 x 185 h
Weight approx. 250 Kg
