Display
Size:4.5”
Resolution:800×480
Connectors
Probe connectors:
2 × BNC or
2 × LEMO-1 or
2 × LEMO-00
Analog output:Alarm
USB1:Type A
LAN:✔
Pulser
Types:Spike + Square Wave (SWP)
Voltage (SWP):
50 V, 100 V,
150 V, 200 V,
250 V, 300 V,
400 V
Energy (SWP):20 ns to 1000ns with 10 ns step Manual & Auto modes
Voltage (Spike):Low: 50 V,
High: 300 V
Damping:✔
PRF modes:Comfort, Low, Medium, High, Manual
PRF:from 15 to 6000 Hz
Phantoms control:3 modes
Receiver
Range (at steel longitudinal wave):314 in(8 000 mm )
Gain:0 to110 dB, with 0.1 dB step
Max signal input:20 V p-p
Bandwidth:0.2 MHz - 27 MHz
Filters:
0.2-27 MHz,
0.2-10 MHz,
2.0-21.5 MHz,
8.0-26.5 MHz,
0.5-4 MHz,
0.2-1.2 MHz,
1.5-8.5 MHz,
5-15 MHz,
0.4 MHz,
0.5 MHz,
1 MHz,
1.25 MHz,
2 MHz,
2.25 MHz,
2.5 MHz,
3.5 MHz,
4 MHz,
5 MHz,
7.5 MHz,
10 MHz,
15 MHz,
20 MHz
Filters set choice:✔
Rectification:RF, FW, Pos. HW,
Neg. HW
TCG (TVG)110 dB;
up to 110 dB/μs slope
Signal AverageOFF / 2x / 4x / 8x / 16x / 32x / 64x
Reject (cutoff)0-80% FSH
Measurement
Number of gates2
Number of cursors2
Modes1, 2, C1, C2, 1-2, 1-C1, 1-C2, 2-C1, 2-C2, C1-C2
TOF ModesPeak, Edge (Flank)
Amplitude measurementup to 220% FSH
Unitsmm / in / us
Output fields5
Alarm
Number of gates2
Number of levels3
Flaws evaluation
AWS✔
DGS (AVG)✔
DAC✔
DAC: Number of points128
DAC codesASME & ASME III,
EN 1712, EN 1713,
EN1714, JIS Z3060,
GB11345, GB 4730
Custom DAC curvesup to 6
DAC 20-80✔
DAC <=> TCG✔
Memory
Setups✔
Datasets (with A-Scans)✔
Capacity2 GB (up to 64 GB)
PC software✔
Other Features
Coupling control✔
AGCindependent for both gates
Quick calibration✔
Quick evaluation (Best signal catch)✔
Auto XX % (50% or 80%)✔
Reference gain✔
Peak hold (collect, peak memory)✔
Signals compare✔
Smart zoom✔
Choice of menu systemsFull
Simple 1
Simple 2
Keyboard backlight✔
Smart (Context) keyboard backlight✔
Number of keyboard shortcuts241
Physical
Dimensions9.5×4.4×5.3"(241×112×135 mm)
Weight incl. battery2 lbs (0.95 kg)
Operating temp. range-22°F to 122°F (-30°C to 50°C)
Dust & water protectionIP65
Battery life8 h
Replaceable battery✔
1 USB Type A (aka Host or Master) allows connecting external devices (a USB stick, a mouse, etc).
