Width: 48 mm
Height: 50 mm
Length: 176 mm
Input Type: N/A
Output Signal: Relay
Response Time: OFF to ON Response: 10 ms max, ON to OFF Response: 12 ms max
Data Interface: CsCAN
LED Indicators: I/O Status (One per Point); Power, Module Status, Network Status
Analog I/O Note: Analog Ouput Note: Rated Load Voltage: 24 Vdc, 220 Vac, Minimum Load Voltage/Current: 5 Vdc/1 mA, Maximum Load Current (Resistive): 2.0 A per channel, 5.0 A per common, OFF to ON Response: 10 mS max;ON to OFF Response: 12 mS max, Output Type: NO
Channel Current: 2.0 A per channel, 5.0 A per common
Input Voltage Note: Absolute Maximum Input Voltage: ±10V
Data Interface Note: Number of Total Nodes: 253;Configuration Method: Module ID set using Two Rotary Switches
Electrical Connection: Removable Screw Terminal
Transmission Distance: 457 m
Number of Channels, Input: N/A
Number of Channels, Output: Relay: 16
