OMEGA OB-102-2 Thermally Conductive Epoxy (Ceramic, Metal, 2 oz)
Manufacturer: OMEGA Model: OB-102-2 - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Volume: 2 oz
Applications: Ceramic, Metal
Working Life: 45 min@ 25°C/77°F; Curing Schedule:Room temp or Heat 16 to 24 hrs @ 25°C/77°F 4 to 6 hrs @ 45°C/113°F 1 to 2 hrs @ 65°C/149°F
Insulation Note: 10¹⁵ ohm-cm ; Very High
Mix Ratio By Weight: 1003.5
Thermal Conductivity: 9.99 BTU-in/h-ft2-°F
Additional Features 1: 2 oz resin, 1/2 oz catalyst
Thermal Conductivity Note: Very High
Operating Temperature, Max: 130 °C
Material Construction Option: Epoxy Adhesive
Mechanical Strength Properties: Tensile Shear: Low stress bonding; Flexible Strength: Low stress bonding
