Height: 56 mm
Memory: 32,000 or 64,000 (depends on setup)
Weight: 900 g
Diameter: 50 mm
Software: Windows 2000/XP/Vista/7 and 8 (32-bit and 64-bit)
Approvals: CE
Materials: 316L Stainless Steel
Resolution: Pressure : 0.01 psi, Temperature : 0.1°C
Battery life: up to 5 yr
Pressure Type: Absolute
Pressure, Max: 2000 psi
Pressure, Min: 0 psi
Sampling Rate: 0.5 Hz (2 seconds between updates)
Control Output: 2 Programmable Alarms
Data Interface: USB
Proof Pressure: 150% Full Scale
Millivolt Range: N/A
Measurement Type: Pressure, Temperature
Supply Power Type: Battery
Sampling Rate Note: User configured 1 every 2 seconds to 1 every 24 hours
Record Trigger Note: Record Trigger: Two independent triggers Multiple Trigger Modes: Instantaneous, button control, on alarm, time and date (Start and Stop), day of week Record Mode: Fill to end of memory or cyclic, number of samples and time duration
Calibration Accuracy: Temperature : ±2 °C, Pressure : ±1%
Battery Size and Type: 3.6V Li-ion
Number of Measurements: 2
Pressure Repeatability: ±0.05%
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -20 °C
Measuring Temperature Range, Max: 85 °C
Measuring Temperature Range, Min: -20 °C
