Specifications
Temp Range:-20 to 300°C (-4 to 572°F)
Working Temp: -10 to 50°C (14 to 122°F)
Working RH: 10 to 80% RH (no dew condensation)
Temperature Resolution: 0.5°C
Accuracy: ±1% of reading or ±3°C whichever larger (at ambient temp of 25°C ±2°C)
Detector: Thermopile array, 48 x 47 pixels
Wavelength: Center wavelength 10µm
Viewable Angle: 25° x 25°
Radius Resolution: 9.1mrad
Frame Speed: 3 fps (1 fps for alarm output)
Focus: Fixed focus
Emissivity: 0.10 to 1.00
Ethernet: 10BASE-T/100BASE-TX
Alarm: 2 SPST (non-voltage contact output)
Power Supply: 12 to 24 Vdc
Power Consumption: Maximum 2.5VA @ 12 Vdc
Inrush Current: Maximum 1A @12 Vdc (the inrush current should be considered for the selection of power)
Casing: Polycarbonate (color: black)
Weight: Approximately 150 g (5.2 oz) (sensor only)
Protection: NEMA 4 (IP65) (with provided exclusive cable and tripod screw)
Standards: CE (EN61326 Annex A)
Standard delivery
Operator’s manual
Software CD
Mounting stand
Power supply
LAN cable
Power/alarm cable
Mounting screws
Plugs, lens and connector caps
