Frequency Range: 1 Hz to 20 kHz (±2 dB)
Responce Type: Free Field Type
Electrode Forming Voltage: 0 V
Sensitivity: -26 dB±1.5 dB re. 1 V/Pa 50 mV/Pa (1 kHz)
Capacitance: 12 pF (Representative Value)
Maximum Sound Pressure Level: 135 dB (When using MI-3170)
Intrinsic Noise Level: 14.0 dB (Representative Value) (When using MI-3170)
Operating Temperature Range: -30 to +80 ℃
Temperature Characteristics: +0.005 dB/K (Representative Value)
Operating Humidity Range: 0 to 90 % (With no condensation)
Humidity Characteristics: -0.0004 dB/% (Representative Value)
Storage Temperature Range: -40 to +70 ℃
Storage Humidity Range: 0 to 90 % (With no condensation)
Outer Dimensions: φ13.2 mm × 16.9 mm
Mass: Approximately 6 g
