Core: ARM Cortex M3
Width: 7 mm
Height: 0.85 mm
Length: 7 mm
Technology: Si
Sensitivity: - 94 dBm
Unit Weight: 1.169 g
Output Power: 6 dBm
Data RAM Size: 76 kB, 88 kB
Data RAM Type: SRAM
Qualification: AEC-Q100
ADC Resolution: 12 bit
Data Bus Width: 32 bit
Interface Type: I2C, SPI, UART
Mounting Style: SMD/SMT
Number of Timers: 4 Timer
Maximum Data Rate: 2 Mbps
Moisture Sensitive: Yes
Operating Frequency: 2.4 GHz
Program Memory Size: 384 kB
Program Memory Type: Flash
Supply Voltage - Max: 3.3 V
Supply Voltage - Min: 1.1 V
Maximum Clock Frequency: 48 MHz
Supply Current Receiving: 2.7 mA
Supply Current Transmitting: 4.3 mA
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
