Rated Output: 0-150V
Voltage : 0-15A
Current : 150W
Power:
Min. Operate Voltage: 0.8V@15A
CV Mode:
Range: 0-150V
Resolution: 1mV
Accuracy: 0.05%+0.05%FS
CC Mode:
Range: 0-15A
Resolution: 1mA
Accuracy: 0.05%+0.05%IFS
CR Mode:
Range: 0.05Ω - 7.5kΩ
Accuracy *1: 0.1%+0.01%R
CP Mode:
Range: 150W
Resolution: 10mW
Accuracy*1: 0.1%+0.1%FS
Dynamic Mode:
T1&T2: 0.1ms-50s
Rise/Fall Slope: 0.01A/ms-2000A/ms
Min. Rise Time: 20μs
Voltage Readback:
Range (V): 0-15V / 0-150V
Resolution: 1mV
Accuracy: 0.05%+0.05%FS
Current Readback:
Range: 0-15A
Resolution: 0.1mA
Accuracy: 0.05%+0.05%FS
Power Readback:
Range: 150W
Resolution: 10mW
Accuracy: 0.1%+0.1%FS
Protection:
Overpower Protection: >OPP, 10ms delay protect
Overvoltage Protection: >OVP, 0.1ms delay protect
Overcurrent Protection: >OCP, 0.1ms delay protect
Overtemperature: 85℃
Optional function: Battery Discharge Test，OCP Test, OPP Test， (Oredr NO. OEL-T1)
Input Power: 100V - 240Vac; 50Hz/60Hz
Interface: RS232,RS485，USB Device， SCPI support
Heat Dissipation: Internal intelligent fan with forced air cooling
Withstand Voltage: 1.5KV / AC / 5mA
Dimension ( W x H x D ): 84mm*151mm*283mm
Device Weight: ≈ 2.5kg
