PCE DM 7 Digital Multimeter (999.9 VDC, 9.999 ADC/AC, 750VAC, True RMS)

Direct voltage DC

Measurement range up to : 0 ... 9.999 mV

Resolution:  0.001 mV

Accuracy: ±(0.5 % of Rd +3 digits)

Direct voltage DC

Measurement range up to: 10 ... 99.99 mV

Resolution : 0.01 mV

Accuracy : ±(0.5 % of Rd +3 digits)

Direct voltage DC

Measurement range up to : 100 ... 999.9 mV

Resolution: 0.1 mV

Accuracy: ±(0.5 % of Rd +3 digits)

Direct voltage DC

Measurement range up to: 1 ... 9.999 V

Resolution: 0.001 V

Accuracy: ±(0.5 % of Rd +3 digits)

Direct voltage DC

Measurement range up to: 10 ... 99.99 V

Resolution: 0.01 V

Accuracy : ±(0.5 % of Rd +3 digits)

Direct voltage DC

Measurement range up to: 100 ... 999.9 V

Resolution: 0.1 V

Accuracy : ±(0.5 % of Rd +3 digits)

Direct current DC

Measurement range up to : 0 ... 9999 µA

Resolution:  1 µA

Accuracy : ±(0.8 % of Rd +3 digits)

Direct current DC

Measurement range up to: 10 ... 99.99 mA

Resolution: 0.01 mA

Accuracy : ±(0.8 % of Rd +3 digits)

Direct current DC

Measurement range up to : 100 ... 999.9 mA

Resolution: 0.1 mA

Accuracy : ±(1 % of Rd +3 digits)

Direct current DC

Measurement range up to : 1 ... 9,999 A

Resolution: 0.001 A

Accuracy : ±(1 % of Rd +3 digits)

Capacity

Measurement range up to : 0 ... 9.999 nF

Resolution: 0.001 nF

Accuracy: ±(5.0 % of Rd +20 digits)

Capacity

Measurement range up to: 10 ... 99.99 nF

Resolution: 0.01 nF

Accuracy : ±(2.0 % of Rd +5 digits)

Capacity

Measurement range up to: 100 ... 999.9 nF

Resolution: 0.1 nF

Accuracy: ±(2.0 % of Rd +5 digits)

Capacity

Measurement range up to: 1 ... 9.999 µF

Resolution: 0.001 µF

Accuracy : ±(2.0 % of Rd +5 digits)

Capacity

Measurement range up to: 10 ... 99.99 µF

Resolution: 0.01 µF

Accuracy : ±(2.0 % of Rd +5 digits)

Capacity

Measurement range up to: 100 ... 999.9 µF

Resolution: 0.1 µF

Accuracy : ±(2.0 % of Rd +5 digits)

Capacity

Measurement range up to: 1 ... 9.999 mF

Resolution: 0.001 mF

Accuracy: ±(5.0 % of Rd +5 digits)

AC voltage

Measurement range up to: 0 ... 9.999 mV

Resolution: 0.001 mV

Accuracy: ±(1 % of Rd +3 digits)

Frequency range: 40 ... 1000 Hz

AC voltage

Measurement range up to: 10 ... 99.99 mV

Resolution: 0.01 mV

Accuracy : ±(1 % of Rd +3 digits)

Frequency range: 40 ... 1000 Hz

AC voltage

Measurement range up to: 100 ... 999.9 mV

Resolution: 0.1 mV

Accuracy: ±(1 % of Rd +3 digits)

Frequency range: 40 ... 1000 Hz

AC voltage

Measurement range up to : 1 ... 9.999 V

Resolution: 0.001 V

Accuracy: ±(1 % of Rd +3 digits)

Frequency range: 40 ... 1000 Hz

AC voltage

Measurement range up to: 10 ... 99.99 V

Resolution: 0.01 V

Accuracy: ±(1 % of Rd +3 digits)

Frequency range: 40 ... 1000 Hz

AC voltage

Measurement range up to: 100 ... 750 V

Resolution: 0.1 V

Accuracy : ±(1 % of Rd +3 digits)

Frequency range: 40 ... 1000 Hz

Alternating current AC

Measurement range up to: 0 ... 9999 µA

Resolution: 1 µA

Accuracy: ±(1 % of Rd +3 digits)

Frequency range: 40 ... 1000 Hz

Alternating current AC

Measurement range up to: 10 ... 99.99 mA

Resolution: 0.01 mA

Accuracy: ±(1 % of Rd +3 digits)

Frequency range : 40 ... 1000 Hz

Alternating current AC

Measurement range up to: 100 ... 999.9 mA

Resolution: 0.1 mA

Accuracy: ±(1.2 % of Rd +3 digits)

Frequency range : 40 ... 1000 Hz

Alternating current AC

Measurement range up to: 1 ... 9.999 A

Resolution: 0.001 A

Accuracy: ±(1.2 % of Rd +3 digits)

Frequency range: 40 ... 1000 Hz

Resistance

Measurement range up to: 0 ... 99.99 Ω

Resolution: 0.01 Ω

Accuracy: ±(1 % of Rd +3 digits)

Resistance

Measurement range up to: 100 ... 999.9 Ω

Resolution: 0.1 Ω

Accuracy: ±(0.5 % of Rd +3 digits)

Resistance

Measurement range up to : 1 ... 9.999 kΩ

Resolution: 0.001 kΩ

Accuracy: ±(0.5 % of Rd +3 digits)

Resistance

Measurement range up to: 10 ... 99.99 kΩ

Resolution: 0.01 kΩ

Accuracy: ±(0.5 % of Rd +3 digits)

Resistance

Measurement range up to: 100 ... 999.9 kΩ

Resolution: 0.1 kΩ

Accuracy: ±(0.5 % of Rd +3 digits)

Resistance

Measurement range up to: 1 ... 9.999 M Ω

Resolution: 0.001 M Ω

Accuracy: ±(1.5 % of Rd +3 digits)

Resistance

Measurement range up to: 10 ... 99.99 M Ω

Resolution: 0.01 M Ω

Accuracy: ±(3.0 % of Rd +5 digits)

Duty cycle

Measurement range up to : 1 ... 99 %

Resolution: 0.1 %

Accuracy: ±(0.1 % of Rd +2 digits)

Frequency

Measurement range up to: 0 ... 99.99 Hz

Resolution: 0.01 Hz

Accuracy: ±(0.1 % of Rd +2 digits)

Frequency

Measurement range up to: 100 ... 999.9 Hz

Resolution: 0.1 Hz

Accuracy: ±(0.1 % of Rd +2 digits)

Frequency

Measurement range up to : 1 ... 9.999 kHz

Resolution: 0.001 kHz

Accuracy: ±(0.1 % of Rd +2 digits)

Frequency

Measurement range up to: 10 ... 99.99 kHz

Resolution: 0.01 kHz

Accuracy: ±(0.1 % of Rd +2 digits)

Frequency

Measurement range up to: 100 ... 999.9 kHz

Resolution: 0.1 kHz

Accuracy: ±(0.1 % of Rd +2 digits)

Frequency

Measurement range up to : 1 ... 5 MHz

Resolution: 0.001 MHz

Accuracy: ±(0.1 % of Rd +2 digits)

Temperature

Measurement range up to: -20 ... +1000 °C

Resolution : 1 °C

Accuracy: ±(2.5 % of Rd +5 digits)

Temperature

Measurement range up to: -4 ... +1832 °F

Resolution: 1 °F

Accuracy: ±(2.5 % of Rd +5 digits)

General technical data

Measuring functions:   HOLD

Display type:   LCD with backlight

Display size:  2.8 Inch

Measuring rate:   3 x per second

Automatic power-off:   5 min

Safety standard:   CAT II 1000 V, CAT III 600 V

Measurement range selection:   Automatic, Manual

Menu language:   English, English (GB)

Protection class (device):   IP20

Weight:   175 g

Operating conditions:   0 ... 40 °C , 0 ... 75 % RH

Storage conditions:   -20 ... 60 °C , 0 ... 80 % RH

(Rechargeable) battery:   2 x 1,5 V AA battery , Alkali-manganese

Capacity:   3000 mAh

Dimensions ( L x W x H ):   140 x 70 x 35 mm

Direct voltage DC:

Electrical specification

Measurement range of direct voltage DC:

Max: 100~999.9 V

Min: 100~999.9 mV

(Direct voltage DC, Capacity, AC voltage, Resistance,...) see on Datasheet

Delivery Scope

1 x Voltmeter PCE-DM 7

1 x temperature sensor

1 x test leads

2 x 1.5 V AA battery

1 x user manual

1 x storage bag
