Ponovo S100A Single Phase Universal Protection Relay Test Set

Range

Frequency: 40Hz~60Hz

Phase angle: 0~359.9°

AC voltage: 3×0-150V

AC current:

Source 1: 0-100A

Source 2: 0-200mA

DC voltage: 0-300V (through Uab)

DC current:

Source 1: 0-10A

Source 2: 0-200mA

Auxiliary DC: 24V/110V/220V

Response time for V and I: <100us

Output power

AC Voltage: Max. 60VA

AC Current: Max. 800VA

Auxiliary DC: 110W at 220V

Binary output

Number: 1

Type Dry contact

Break capacity AC: Vmax: 250V (AC) / Imax: 0.5A

Break capacity DC: Vmax: 250V (DC) / Imax: 0.5A

Binary inputs

Number: 2

Type: 15V-250V(DC) or potential free

Sample rate: 5KHz

Resolution: 1ms

Isolation: Independent galvanic isolation

Dimesion: 364 mm×155.5 mm×415mm (W×H×D)

Weight: 18 kg
