Measuring range: 0.001-100 NTU
Measurement accuracy: 0.001-40 NTU: ±2% or ±0.015 NTU bigger one / 40-100 NTU: ±5%
Repeatability: ≤2%
Resolution: 0.001-0.1NTU,base on different range
Display: 3.5 inch LCD screen
Sample Flow: 200mL/min≤X≤400mL/min
Calibration: Sample calibration, slope calibration
Pipe Fittings
Water inlet: Quick-connect switch to hard pipe φ8
Outlet: Quick-connect to hard tube φ12
Cleaning port: Quick-connect to hard tube φ12
Sensor Main Material: Body:ASA;Cable:PUR
Power: Sensor 9-36VDC / Standard with 220VAC to 12VDC power converter
Relay: 1 way relay
Output: 1 way 4-20mA
Communication: MODBUS RS485
Storage Temp.: -15-60℃
Operating Temperature: 0-45℃(Non-freezing)
Dimension: 158*166.2*155mm(L*W*H)
Weight: 1KG
Protection Rate: IP65(Indoor)
Applications
Turbidity online monitoring of tap water plant pre-filtration, post-filtration, factory water, direct drinking water system
Turbidity online monitoring of various industrial production circulating cooling water, filtered water, water reuse system, etc.
Online monitoring of turbidity in various industrial production circulating cooling water, filtered water, water reuse system and other links.
