Phase: 1Ø
Power Rating: 500VA
Voltage:
-Range: 0 - 300V
- Resolution: 0.1 V
- Accuracy: ±(1% of setting + 2 counts)
Max. Current (r.m.s)2
0 - 150V: 4.6A
0 - 300V: 2.3A
Frequency:
Range: 40 - 500Hz Full Range Adjust
Resolution: 0.1Hz at 40.0 - 99.9 Hz, 1Hz at 100 - 500Hz
Accuracy: ±0.03% of setting
Line Regulation: ± 0.1V
Load Regulation: ±(0.5% of output + 0.5V) at Resistive Load
DC OUTPUT (Optional)
Protection: OCP, OVP, OPP, OTP, LVP, Short Circuit ; Alarm and shutdown
Interface: Standard USB & RS232, Optional GPIB, Ethernet, PLC Remote Input Card (select one)
Op./Non-Op. Temp./Humidity: 0~40°C/-40~75°C/20~80%RH
Dimension(W x H x D): 430 x 89 x 400 mm
Weight: 16.5kg
Accessory: Power Cable (10A)
