DIGITAL BROADCAST STANDARDS
DIGITAL BROADCAST STANDARDS:DVB-T, DVB-T2, DVB-T2 lite, ATSC, ISDB-T/TB, J.83B
DVB-C, DVB-C2
DVB-S, DVB-S2
DVB-S2 Multistream
DSS, ACM / VCM / CCM
DAB, DAB+ (optional)
AUDIO CODECS:MPEG-1, MPEG-2, HE-AAC, Dolby Digital, Dolby Digital Plus
VIDEO CODECS:MPEG-2, MPEG-4 / H.264, HEVC / H-265
INPUTS AND OUTPUTS:Universal RF input 75 Ω
HDMI output
IP input for remote control
Analogue Video/Audio input
2 x USB (Type-A) for data transfering
SPECTRUM ANALYZER
Frequency Margin: From 5 to 1000 MHz (Terrestrial) ; From 250 to 2500 MHz (Satellite)
Measurement range: From 10 to 130 dBμV
Span: Full / 500 / 200 / 100 / 50 / 20 / 10 MHz
Resolution bandwidths:100, 200 kHz, 1 MHz
MEASUREMENT MODE
(According to standards)
Frequency Margin: From 5 to 1000 MHz (Terrestrial); From 250 to 2350 MHz (Satellite)
DVB-T COFDM: Power (35 to 115 dBμV), CBER, VBER, MER, C/N, Link margin
DVB-T2 Base and Lite COFDM: Power (35 to 115 dBμV), CBER, C/N, LBER, MER, Link Margin, BCH ESR, Iterations LDP, Wrong packets
DVB-C QAM: Power (45 to 115 dBμV), BER, MER, C/N and Link margin
DVB-C2 COFDM: Power (45 to 115 dBμV), CBER, MER, C/N, LBER, BCH ESR, Iterations LDP and Wrong packets
PAL, SECAM and NTSC analogue TV: M, N, B, G, I, D, K y L
FM radio: Level measurement
DVB-S QPSK: Power (35 to 115 dBμV), CBER, MER, C/N y Link Margin
DVB-S2 QPSK, 8PSK, 16APSK, 32APSK: Power (35 to 115 dBμV), CBER, LBER, MER, C/N, BCH ESR, Wrong packets and Link Margin
DSS QPSK: Power (35 to 115 dBμV), CBER, VBER, MER, C/N and Link margin
INTERNAL STORAGE: 7 GB for measurement protocols, screenshots and transport stream recordings
PC CONNECTION (via ethernet interface): SNMP and WEB SERVER
MECHANICAL FEATURES
Dimensions and Weight:482.6 (W.) x 44.4 (H.) x 381 (D.) mm.; 2.9 kg
OPTIONS:DAB, DAB+; GPS Coverage Analysis ; OPM + Optical-to-RF converter + WiFi 5 GHz + LTE 2.6 GHz +
6 GHz RF input; WiFi 5 GHz; LTE 2.6 GHz + 6 GHz RF input
