DIGITAL BROADCAST STANDARDS:
ATSC
DVB-C, QAM Annex B
DVB-S, DVB-S2
DVB-S2 Multistream
DSS, ACM / VCM / CCM
DAB, DAB+ (optional)
AUDIO CODECS: MPEG-1, MPEG-2, AAC, HE-AAC, Dolby Digital, Dolby Digital Plus
VIDEO CODECS: MPEG-2, MPEG-4 / H.264, HEVC / H.265
INPUTS AND OUTPUTS:- Universal RF input 75 Ω
- HDMI output
- IP input for remote control
- Analogue Video/Audio input
- 2xUSB (Type-A) for data transfering
FUNCTIONS:Constellation diagram
LTE ingress test
Dynamic echoes analysis
StealthID (instant identification of tuning parameters)
PLS (Physical Layer Scrambling)
Screenshots and Datalogger for
Service recording
Ultra fast spectrum analyzer (70 ms sweep time
measurement reports
Field strength measurement
Beacon-Flyaways for SNG & VSAT
Task planner
4K Frame grabber
Wideband LNB
MAX and MIN hold
WiFi 2.4 GHz
FM RDS radio measurement and decoding
LTE 1.8 GHz
OTT
Spectrogram
Signal monitoring
Remote control (webControl
MER by carrier
Video/Audio Streaming
SCAN + TILT
Shoulder attenuation
SPECTRUM ANALYZER
Frequency Margin: From 5 - 1000 MHz (Terrestrial)
From 250 - 2500 MHz (Satellite)
Measurement range Span : From 10 - 130 dBµV
Full / 500 / 200 / 100 / 50 / 20 / 10 MHz
Resolution bandwidths:100, 200 kHz
1 MHz
MEASUREMENT MODE (please refer to STANDARDS section)
Frequency Margin: From 5 - 1000 MHz (Terrestrial)
: From 250 - 2350 MHz (Satellite)
DVB-T COFDM :Power (35 to 115 dBμV), CBER, VBER, MER, C/N, Link margin
DVB-T2 Base and Lite COFDM: Power (35 to 115 dBμV), CBER, C/N, LBER, MER, Link Margin, BCH ESR, LDP iterations, Wrong packets
DVB-C QAM: Power (45 to 115 dBμV), BER, MER, C/N, Link margin
DVB-C2 COFDM: Power (45 to 115 dBμV), CBER, MER, C/N, LBER, BCH ESR, LDP iterations, wrong packets
PAL, SECAM and NTSC: M, N, B, G, I, D, K and L
FM radio :Level measurement
DVB-S QPSK: Power (35 to 115 dBμV), CBER, MER, C/N, Link Margin
DVB-S2 QPSK, 8PSK, 16/32APSK: Power (35 to 115 dBμV), CBER, LBER, MER, C/N, BCH ESR, Wrong packets, Link Margin
DSS QPSK :Power (35 to 115 dBμV), CBER, VBER, MER, C/N, Link margin
INTERNAL STORAGE: 6 GB for measurement protocols, screenshots and transport stream recordings
PC CONNECTION (via ethernet interface): NetUpdate 4 (free software) + Free and automatic firmware updates + User customised channel plans+ Measurement reports and screenshots
GENERAL:Hybrid operation: Touch screen (7”) or conventional keyboard
DiSEqC 2.x generator (DiSEqC 1.2 commands implemented)
dCSS / SCD 2 (EN50607) and SATCR/SCD (EN50494)
BATTERY: > 4h(smart battery)
HARD CASE: Included
OPTION:
DAB, DAB+: Available
GPS Coverage Analysis: Available
Advanced DAB/DAB+ analyzer: Available
Advanced FM radio analyzer: Available
Rack assembly 19” 4U: 482 (W.) x 178 (H.) x 205 (D.) mm: Available
OPM + Optical-to-RF converter + WiFi 5 GHz + LTE 2.6 GHz + 6 GHz RF input: Available
WiFi 5 GHz + LTE 2.6 GHz + 6 GHz RF input: Available
