Metrological parameters:
E1 Calibration Range : 100 g – 1 kg
E2 Calibration Range : 100 g – 1 kg
F1 Calibration Range : 100 g – 1 kg
F2 Calibration Range : 100 g – 1 kg
Maximum capacity [Max] : 1002 g
Readability [d] : 0.1 µg
Standard repeatability [5% Max] : 0.4 µg
Standard repeatability [Max] : 0.5 µg
Permissible repeatability : 1 µg
Electric compensation range : -1 g – +2 g
Stabilization time : 60 s
Adjustment : external
Physical parameters:
Display : 10″ graphic colour touchscreen
Weighing pan dimensions : ø100 mm
Vacuum chamber dimensions : 965×745×1150 mm
Pressure range : 10^(-6) mbar
Object diameters : cylindrical ø (22 – 95)x110; spherical ø (40 – 100)mm
Weighing device dimensions : 965×745×1700 mm
Controling device dimensions : 249×170×72 mm
Net weight (without table) : 250 kg
Net weight (with table) : 650 kg
Communication interface:
Communication interface : 2×USB-A, USB-C, HDMI, Ethernet, Wi-Fi, Hotspot
Electrical parameters:
Power supply : 100 – 240 V AC 50/60 Hz
Environmental conditions:
Operating temperature: +15 – +30 °C
Operating temperature change rate : ±0.1 °C / 12 h
Relative humidity : 45% – 60%
