E1 Calibration Range: 2 g – 50 kg
E2 Calibration Range: 2 g – 50 kg
F1 Calibration Range: 2 g – 50 kg
F2 Calibration Range: 2 g – 50 kg
Maximum capacity [Max]: 50 kg
Readability [d]: 10 µg
Standard repeatability [Max]: 1.6 µg
Standard repeatability [5% Max]: 0.6 µg
Stabilization time: 10 s
Adjustment: internal (automatic)
Calibration Range: 2 g – 50 kg
Distance platform Z0: 18; 20; 27; 35; 43 mm
Magnetizing field strenght: 2700, 2000, 800, 380, 200 A/m
Physical parameters
Display: 10″ graphic colour touchscreen
Physical parameters
Weighing chamber doors: automatic
Weighing pan dimensions: ø300 mm
Device dimensions W x D x H: 525×350×250 mm
Packaging dimensions W x D x H: 950×750×750 mm
Net weight: 26 kg
Dipole moment of magnets: ≤ 0.1 Am2
Communication interface: 2×USB-A, USB-C, RS 232 (COM3), HDMI, Ethernet, Wi-Fi, Hotspot
Operating temperature: +15 – +30 °C
Operating temperature change rate: ±0.5 °C / 12 h (±0.3 °C / 4 h)
Relative humidity: 40% – 60%
Relative humidity change rate: ±2% / 4 h
Construction
Housing: ABS plastic
Processor: 2×1 GHz
Memory: RAM 256 MB DDR2, 16GB – microSD
