GNSS
Signal Tracking: GPS (L1C/A, L1C, L2C, L2P, L5)
GLONASS¹ (L1C/A, L2C, L2P, L3, L5)
BeiDou² (B1, B2, B3)
Galileo³ (E1, E5AltBOC, E5a, E5b, E6); IRNSS (L5)
QZSS (L1C/A, L1C, L2C, L5, L6); SBAS (L1, L5)
L-Band (Up to 5 Channels) TerraStar®
No. of Channels 555
MEASUREMENT PERFORMANCE
Real-time Kinematic: H: 8mm + 1ppm RMS / V: 15mm + 1ppm RMS
Network RTK: H: 8mm + 0.5ppm RMS / V: 15mm + 0.5ppm RMS
Post Processing Kinematic: H:8mm + 1ppm RMS / V:15mm + 1ppm RMS
High-precision Static: H: 2.5mm + 0.1ppm RMS / V: 3.5mm + 0.4ppm RMS
Static and Fast Static: H: 2.5mm + 0.5ppm RMS / V: 5mm + 0.5ppm RMS
DGPS Position Accuracy: H: 25cm RMS / V: 50cm RMS
SBAS Position Accuracy: H: 50cm RMS / V: 85cm RMS
Code Differential: DGPS/RTCM
Initializing Time: <10s
Initializing Reliability: 99.9%
COMMUNICATIONS
Communication Ports:
USB and RS232 serial port
Bluetooth 4.0, NFC
DC External power input
LED indicator panels
GENERAL Environmental
IP67 environmental protection
Waterproof to 1m (3.28ft) depth
Temporary Submersion
Shock resistant body to 2m (6.5ft) pole drop
Temperature -40°C to 65°C Operating
-40°C to 75°C Storage
Physical Properties Size: 127.5mm x 57mm
Weight: 700g including battery
Power: 6 – 28V DC Input
Battery: 6300 mAh Li-Ion Battery
Battery Life: 9 hours (Static Measurement / RTK Rover)
