Frequency range: DC - 1 MHz (Small signal -3 dB)
Power band: DC – 200 kHz
Slew rate: 100 V/µs
Offset: ± 1 mV (± 0.1 mV / °C)
Voltage gain: 10 ± 0.1 % (± 0.01 % / °C)
Option ultra stable gain: 10 ± 0.1 % (± 10 ppm/°C)]
Output voltage: 50 Vrms / ± 75 Vpeak
Output current: 16 Arms / ± 24 Apeak
Distortion: (DC – 100 kHz, Load ≥ 4 Ω) < 0.10%
Input impedance: 100 kΩ
Output impedance: << 1 Ω and 50 Ω
Max. input voltage:80 V (cont.), 100 V (< 1 min)
Broadband noise: (10 Hz – 1 MHz, Input 50Ω) 0.5 mVrms
Power dissipation: (each side): 820 W (100 ms)
Mains voltage: 230 VAC / 50 Hz
Remote control USB
Generator Specifications
Frequency range: DC, 0.05 Hz - 300 kHz; resolution 0.05 Hz
Frequency precision: ± 20 ppm
Signal types: Sine, Square, Triangular
Machanical data
Dimensions: (W x H x D) 449 mm x 177 mm x 585.5 mm (4HE)
Weight app. 32 kg
