Power supply
Supply voltage : 230 V AC ±10 %
Frequency AC : 47..63 Hz
Power consumption : < 3.5 VA
Operating temperature : -10..+60 °C
CE-conformity : EN 61326-1:2013
EN 60664-1:2007
Input
Thermocouple
Type J : Fe-CuNi, in range -100..+800 °C
Type K : NiCr-Ni, in range -150..+1200 °C
Type S : Pt10Rh-Pt, in range 0..+1600 °C
Output
Current : 0..20 mA, 4..20 mA switch selectable, burden ≤ 500 Ω
Voltage : 0..10 V, 2..10 V switch selectable, load max. 10 mA , short-circuit-proof
Start value : adjustable approx. ± 5 %
End value : adjustable approx. ± 5 %
Broken line : outputs takes the end value +1 %, overflow indication
Short-circuit : no indication (output takes terminal temperature)
Accuracy : ≤ 0.15 %, 1 °C
Temperature coefficient : ≤ 0.01 %/K
Case : Polycarbonate, UL94 V-0
TS35 acc. to DIN EN 60715:2001-09
Weight : approx. 200 g
Connection : screw terminals with pressure plate max. 2.5 mm²
Protection class : case IP30 terminals IP20 acc. to BGV A3
