Detection Range
Feet: 50-132
Meters: 15-40
Detected Gas: C1-C8
Response Time: 3 sec.
Sensitivity Range:
0-5 LEL.m methane and propane
0-8 LEL.m ethylene
Spectral Response: 2.0 - 3.0µm
Displacement/Misalignment Tolerance: ±0.5°
Drift: ±7.5% of the reading or ±4% of the full scale (whichever is greater)
Minimum Detectable Level: 0.15 LEL.m
Temperature Range: –67°F (–55°C) to 149°F (65°C)
Power Supply: 24VDC nominal (18-32 VDC)
Power Consumption:
Detector: 250mA (300mA Peak) (peak includes heated optics)
Source: 250mA (300mA Peak)
Warm Up Time: 30 sec for transmitter and receiver
RS-485 Interface – Modbus: The RS-485 input/output provides complete data information to a PC and receives control commands from the PC or handheld unit
HART: HART communications on 0-20mA analog current (FSK) – used for maintenance and asset management
Dimensions:
Detector/Source: 10.5 x 5.1 x 5.1 inch (267 x 130 x 130mm)
Tilt Mount: 4.7 x 4.7 x 5.5 inch (120 x 120 x 158mm)
Weight:
Detector/Source: 11lb (5kg)
Tilt Mount: 4.2lb (1.9kg)
Water and Dust Tight: IP66 and IP68 NEMA 250: 6P
