Swing over bed: 180 mm
Distance between centers Model 200: 200 mm
Model 300:300 mm
Hole through spindle:20 mm
Cross slide travel:65 mm
Compound travel:55 mm
Spindle taper:MT3
Tailstock taper:MT2
Spindle speed Low range:100-1100 ±10% rpm
High range:100-2500 ±10% rpm
Motor output power: 250 W
Range of threads Metric version:0.4-2.0 mm (10 thread pitches)
Imperial version:12-52 TPI (18 thread pitches)
Overall dimension(LxWxH)Model200:600x300x300 mm
Model 300:700x300x300 mm
Weight (Net/Gross) Model 200:33/36 kg
Model 300:37/40 kg
Packing size (LxWxH) Model 200:690x360x390 mm
Model 300:790x360x390 mm
