Application: Windings of power transformers, instrument current transformers,
electromagnets and electric motors; Compensatory, current-limiting and
other resistors of high-voltage circuit breakers; Contacts and contact connections of power and signal circuits; Cables.
Resistance range: 10 µOhm ÷ 2 kOhm
Maximum permissible intrinsic error of resistance measurement: ±(0.1%+0.5µOhm)
Measuring current intensity, А: 0,015 ÷ 10
Relative drift of measuring current intensity, %/s: ±0.002
Maximum consumed power, W120
Maximum output capacity, W60
Mains voltage: AC (giá trị cho phép)90 ÷ 253V
Mains voltage: DC127 ÷ 354V
IP rating in operating state: IP20
IP for transportation: IP64
Operating temperature range, ºС: -20 ÷ +50
Maximum measuring unit weight, kg: 2.7 (Without battery)
Dimensions, mm: 270х250х130
Interface language: English
User manuals language: English
Calibration interval, year: 3
Standard complete set:
+ MIKO-7M measuring unit
+ Mains cable СКБ031.23.00.000
+ Ground wire СКБ010.01.00.000
+ Zero resistance equivalent СКБ023.15.00.000
+ Shunt 75ШСММ3
+ VP2B-1V-2А cut-out (2 pcs.)
+ Attachment devices set kit
Additional complete set (on order)
Measuring cable СКБ031.18.00.000
Measuring cable СКБ031.21.00.000
Measuring cable СКБ031.19.00.000
Measuring cable with a fast-switching ground clamp
Measuring cable extension (set of 2 pcs.) СКБ031.20.00.000
Battery power cable СКБ031.17.00.000
Software
Cable USB 2.0 A-B
Reference inductor adaptor СКБ023.12.00.000
Cable and documentation bag СКБ126.06.00.000
Manipulating rod
СКБ010.41.00.000
СКБ010.41.00.000-01
СКБ010.41.00.000-02
