Maximum coupling height: 45 mm
Maximum coupling height with extension: 170 mm
Alignment methods
3 position measurement 9 -12 -3
Automatic measurement
Free measurement (only 40° shaft rotation needed)
Recommended applications
Horizontal shafts
Vertical shafts
Soft foot
Live correction values: Vertical and horizontal
Special features
Machine library
Pictures in reports
QR code reading
Target values
Disturbance compensation
Free 3D machine view
Screen rotation on tablets
Automatic .pdf report
Sensors
20 mm PSD
Inclinometer ±0.1°
Communications: Bluetooth 4.0 LE
Measurement distance: 0.07 to 5 m
Measuring error (percent): 1 %
Material: Measurement units: anodized aluminum front and PC/ABS plastic back cover
Battery: Measuring units: rechargable 2000mAh Li-ion battery
Battery life: 10 h
Operating temperature range: 0 – 45 °C
Display: None, Smartphone or tablet needed
Operating system
min. Android 9
min. Apple iOS 9
Software update: Via Apple AppStore and Google Play Store
Suitable operating devices
Android Tablet or Smartphone with min. Android 9
Apple iPad, iPhone with min. iOS 9
Laser type: Red line
Mounting: 2x V-brackets (width 15 mm) with chains and magnets
Shaft diameter: 20 to 150 mm
Shaft diameter with extension: Up to 450 mm with extension chains (included)
Power adapter
Charging via micro USB 2.0 port (5V)
Micro USB to USB charging cable included
Compatible with standard 5V USB chargers (not included)
