Direct access to our certified experts
Output: Voltage (0 – 100mV)
Measuring range: Depends on the probe connected
Display range:
- Temperature : -15 to 65.0°C
- Humidity : 5 to 99.9%rh
Measuring accuracy: Depends on the probe connected
Output accuracy:
- Temperature :±0.3°C
- Humidity: ±0.3%rh
Resolution:
- Temperature: 0.1°C (at >-9.9°C); 1°C (at other range)
- Humidity: 0.1%rh (at >15%rh); 1%rh(at other range)
Display accuracy:
- Temperature: ±(0.1+1digit)°C
- Humidity :±(0.1+1digit)%rh
Output:
- Temperature: -10 to 60°C / -10mV to 60mV
- Humidity: 0 to 100%rh / 0 to 100mV
- Impedance: 500Ω
Power requirement: 12 to 24VDC or AC adapter (9VDC / 500mA)
Functions:
- Upper/lower limit output (relay contact)
(Max. rate of alarm output: Voltage resistance: 48VAC/DC continuous load current: 1A)
- Sampling( switchable at 1 sec. and 10 sec.)
Materials:
- Main body: ABS resin
- Display: Acryl resin
Dimensions/Weight: 118(W) x 100(H) x 42(D)mm, approx. 220g
Accessories: One fixing screw to fasten the probe
