Measuring Range: C（0.005%~100%） H（0.01%~50%） N（0.01%~50%）
Reproducibility: Cd≤1.00% Hd≤0.25% Nd≤0.15%
Repeatability: Cad≤0.5% Had≤0.15% Nad ≤ 0.08%
Auto loader: 36/72 Samples
Analysis time: ≤5min/Sample
Sample Mass: 75~105mg（Recommended：100mg）
Analysis Method: CH：Infrared Absorption N：Thermal Conduction
Combustion Supporting Gas: Oxygen Purity：≥99.5% Pressure：≥1MPa
Carrier Gas: Helium Purity：≥99.99% Pressure：≥1MPa
Driving Gas: Nitrogen / Dry Compressed Air Pressure：≥1MPa
Preheating Time: ＜2.5hour
Sample Adding/Replacing Function: Available
Auto Analysis: Yes
Crucible Replacing: Automatic
Furnace Temperature: Combination Furnace，950℃±5℃ Reduction Furnace：700℃±5℃
Air Tightness Detection: Automatic
Humidity: 20%to 85%, non-condensing
Ambient Temperature: 15 ℃ to 28℃
Power requirement: AC 220 V（-15%~10%）50/60Hz
Max.Power: 4.5kW
Dimensions: 710*650*1045mm
Weight: 140kg
Advance Calculation: Yes
Analysis Report: Yes
Statistics Report: Yes
System Monitor: Yes
