Hãng sản xuất: SYNEO
Model: AEP-8T
Bảo hành: 12 tháng
Opening 56 CM x 61 CM deep (22" x 24")
PCB 46 CM x 61 CM (18" x 24")
All electric press, hi-frame design
5-ton capacity
Windows PC control with touchscreen monitor, keyboard, mouse
Full force available throughout travel
Head is manually moveable throughout opening
Flat rock press head 203 MM x 38 MM (8" x 1.5")
Teflon Hard Coat aluminum table
Two-hand safety actuation
Press to force or height with error detection
Dynamic force adjustment using PAST, PAR or FAT
Machine Vision bar code reading and PCB locating
Fully automatic setup
Board thickness measurement
16" maximum tool length
Press to force or height with error detection
Manual head rotation (0, 90 degrees)
110 or 220 VAC 1 phase, 15 Amps, 50/60 Hz
Air 80 psi for air table only
350 lbs. approx. weight
Shipping: 1 pallet, 152 CM x 122 CM x 140 CM high, 500 lbs
Press Force: 5 Tons
Two Stage Force(2SF): OPTIONAL
True Distance Measurement (TDM): OPTIONAL
Board Size: 580mm x 800mm
Press Anvil Size: 279mm x 38mm
Dimensions: 870 x 830 x 1120mm
