Temperature control method: Band heater (PID control) with anti-excessive temperature rise function (Max. 80 [℃])
Power transmission: Linear shaft drive non-sealing type
Gas supply device: Sintered metal type *Optional
Temp. control range: Room temperature + 5 to 20℃ (normally set to 37℃)
Temp. accuracy: ±0.3[℃]（37[℃]）
Max. up/down motion amplitude: 40[mm]
Max. impeller speed: 300[mm/s]
Temperature setting: Digital setting, data output 1 - 5 [V]
Up/down motion setting: Touch panel input, data output 1 - 10 [V]
Band heater: 105 [W]
Mixer motor: Max. power 800 [W]
Mixing impellers: VM100+VM200
Culture tank Dimensions/Total capacity: I.D. 110 x Depth 169 [mm] / 1.5[L]
Environment temp. range: 10 to 35[℃]
Outer dimensions: W360×H905×D485 [mm]
Weight: approx. 28[kg]
Power supply: AC 100[V], 50/60[Hz]
*The performance is the value under room temperature 20℃, power supply AC 100 [V], 50 [Hz] and no load condition.
![TAITEC VMF-10000 BioReactor (80 [℃]; 480 [W])](/s-cdn/f1/f18660a37ffcb2fa7afe5a0412ec204cf63fb473.jpg)
![TAITEC S-BOX×10αII Culture Controller For Bioreactor (0.00 ~ 14.00 [pH]; 0.00 ~ 20.00 [mg/L]; 0.00 ~ 20.00 [mL/min])](/s-cdn/3d/3da0ef29e5e6c30a85ce31d0733d60320e72df49.jpg)
