Compliance: ISO 11452-4; MIL-STD-461 CS114, GJB 151B-2013, DO-160
Characterized freq. range: 10 kHz to 500 MHz
Insertion loss: 5 dB typ.; 50 Ohm system (100 Ohm loop impedance)
Transfer impedance: 29 dB Ohm typ.; 50 Ohm system (100 Ohm loop impedance)
Power rating: capable of injecting severity levels I, II, III, IV according to ISO 11452 and customer specified level V up to 350 mA
Max. core temperature: 80 °C
Connector type: BNC-SHV
male Aperture diameter: 27 mm
Outside diameter: 92 mm
Height: 76 mm
Weight: 1.2 kg
