Electrical Specifications
Adjustable Output Voltage: 0 to ±25 V RMS
External Input Voltage: 0 to 5 VDC Square Wave
Voltage Resolution: 1.0 mV
Adjustable Internal Modulation Frequency: 0.5 to 150 Hz at 50% Duty Cycle
Switching Frequency: 2,000 ± 5 Hz, 50% Duty Cycle
Slew Rate: 10 V/µs
DC offset: ±10 mV
Max Output Current: 15 mA
AC Power: 85 - 264 VAC, 47 - 63 Hz, 25 VA
Fuse Rating: 125 mA, 5 x 20 mm SLO-BLO
Warm Up Time: 30 Minutes
Physical Specifications
External Input Connector: BNC
External Input Enable: Front Panel: INT/EXT enable Key
External Input Indicator: Green LED
Output Connector: BNC
Output Enable: Front Panel: OUTPUT ENABLE Key
Output Indicator: Green LED
Rotary Knob: Digital Encoder
Display: LCD 16 x 2
Power Switch: Rocker Switch
USB interface: USB Standard B Plug
Dimensions: 5.75" x 3" x 12.2" (146 mm x 78 mm x 309 mm)
Weight: 3.6 lbs
Operating Temperature Range: 10 to 40°C
Maximum Relative Humidity: 85%
Other: Tilting Rubber-Padded Feet
