Wavelength Range: 190 nm - 20 µm
Optical Power Working Range(a): 100 µW - 1 W
Active Sensor Area: 4.4 mm x 4.4 mm (0.17" x 0.17")
Item # of Mounted Sensor: TD4X
Max Average Power Density(b): 1.5 kW/cm²
Max Pulse Energy Density: 0.3 J/cm2 (1 ns Pulse), 5 J/cm2 (1 ms Pulse)
Detector Type: Thermopile
Typical Responsivity: >100 mV/W
Linearity with Optical Power: ±0.2%
Rise Time(c): 1.1 s
Active Area Uniformity: ±1% (>1 mm Beam Diameter)
Temperature Sensor: NTC Thermistor, 10 kΩ
Detector Dimensions: 18.0 mm x 12.0 mm x 2.6 mm (0.71" x 0.47" x 0.11")
Substrate: PCB
Mounting(a): Two Ø3.3 mm (Ø0.13") Mounting Holes
Electrical Connection: Wire
(a) Mounting on an appropriate heat sink is required. For mounting instructions and other information, see the Handling Instructions manual.
(b) Damage Threshold
(c) Typical Natural Response Time (0 - 95%)
