Test force:
2.94n(0.3kgf), 4.90n(0.5kgf), 9.80n(1kgf), 19.6n(2kgf), 24.5n(2.5kgf), 29.4n(3kgf), 49n(5kgf), 98n(10kgf)
Test Range: 1HV~2967HV
Loading Method: Automatic (Loading/Dwell/Unloading)
Shifting between Objective and Indenter: Automatic
Total Magnification: 100×, 400×
Resolution: 0.25μm, 0.0625μm
Dwell Time: 0~60s
Light Source: Halogen Lamp
X-y Test Table
Size: 100×100mm; Travel: 25×25mm; Resolution: 0.01mm
Max. Height of Specimen: 170mm
Throat: 130mm
Power Supply: AC220V, 50Hz
Execute Standard:
ISO 6507, ASTM E92, jIS Z2244, GB/T 4340.2
Dimension:
530×280×630mm
Packing Dimension: 620×450×740mm
Weight (kg) net Weight: 35
Gross Weight: 47
Standard Delivery
Instrument Main Body
Diamond Vickers Indenter
Cross Test Table
4 x Horizontal Regulating Screw
2 x Fuse 1A
Inner Hexagon Spanner 2.5mm
Hardness Block 700~800 HV1
Anti-dust Cover
10× Digital Measuring Eyepiece
10×、40× Objective
Power Cable
Level
Halogen Lamp 12V、15~20W
Screw Driver
Hardness Block 700~800 HV10
Usage Instruction Manual
