Range: (Manual or Automatic): 1.0000mOhm to 100.00kOhm
Resolution: 0.1μOhm
Over range: 80% to 18,000
Max. Uncertainty: 0.03% read. + 2dgt
Measuring Speed/Time: 10 measurements/second
Display: 4-½ digits
Current @ 1 mOhm 1 A
10 mOhm 1 A
100 mOhm 100 mA
1 Ohm 10 mA
10 Ohm 1 mA
100 Ohm 1 mA
1 kOhm 100 μA
10 kOhm 100 μA
100 kOhm 10 μA
Measuring Voltage: 4V (20mV limit for contacts)
Max. Inductive Power: < 100 VA
Temperature Comp.: With PT100 Probe Range 20°C/23°C
Temp. coefficient: Off, Cu or Al
Zero Correction: Compensated at each measurement
Input Protection: Against inductive spikes
Error detection display and message (RS232):
Open potential leads: ‘SEN’ (‘ESEN’)
Open current leads: ‘CUR’ (‘ECUR’)
Over range >80%: ‘OVR’ (‘EOVR’)
Limits: 0... 18,000 upper/lower
Limits overrun display and message (RS232): > or < in front of measured value; '>’ or ‘<’ as first sign of message
Limit settings: Manual (keys) or RS232
Ports/Interface: RS232, Parallel Printer, PLC
Measuring Start Via: Key, RS232, PLC, Potential free contact
Dimensions: 280 x 80 x 240 mm (W x H x D)
Weight: Approx. 3kg
Environment: -10°C to 40°C; -20°C to 60°C; <95% Humidity, not condensing
