TEST CURRENTS: Up to 100 A (True DC).The test current can be set between 10% and 100% of the working stream with a resolution of 1 A.
RESISTANCE RANGES: 0.1 µΩ to 300 mΩ.
MEASUREMENT PRINCIPLE: Four-terminal, Kelvin-type.
THERMAL PROTECTION: Protects all sensitive components, avoiding any damage due to overheating.
PROGRAMMABLE TEST TIME: Allows to setup the test time from 5 seconds up to 120 seconds.
BASIC ACCURACY: ± 1 % of reading ± 1 digit.
ADVANCED FEATURES: Digital direct reading of very low resistances in the alphanumerical display, with up to 4½ digits.
Very fast and accurate measurements.
BUILT-IN PRINTER: Allows print the measured values.
BUILT-IN MEMORY: Capacity to store 50 registers with 80 readings each.
SERIAL DATA OUTPUT: USB.
TINSLEY SOFTWARE: Friendly, easy to use software. With automatic report generator, including the operator's commentaries.
ENVIRONMENTAL: IP54 with closed lid.
SAFETY CLASS: Meets the requirements of IEC 61010-1.
POWER SUPPLY: Mains: 90-240 V~ 50/60 Hz auto.
OPERATING TEMPERATURE RANGE: -5 °C to +50 °C.
STORAGE TEMPERATURE RANGE: -25 °C to +70 °C.
HUMIDITY RANGE: 95% UR (non condensing).
EQUIPMENT WEIGHT: Approx. 11 kg.
ACCESSORIES WEIGHT: Approx. 20.5 kg.
DIMENSION: 502 x 394 x 190 mm.
AVAILABLE ACCESSORIES:
2 Combined test leads (current and potential), clamp type “C” (sargent).
1 Power cord.
1 Ground cable.
1 Communication cable.
1 Carrying case the test leads.
1 License to use the software.
1 User guide.
